Getting Started

PopGames is a Python library for modeling and simulating population games.

Source Code

🔗 GitHub repository:
https://github.com/Martinez-Piazuelo/popgames

Installation

PopGames is available on PyPI and can be installed using pip.

Install from PyPI

pip install popgames

This installs the latest released version together with its dependencies.

Install the development version

If you want the latest features, you can install the development version directly from GitHub:

pip install git+https://github.com/Martinez-Piazuelo/popgames.git

Verify the installation

You can verify that PopGames is installed correctly by running:

import popgames
print(popgames.__version__)

If no errors occur, the installation was successful.

Quick Usage Example

PopGames follows an object-oriented design built around four core components:

  • Population game: defines the strategic environment

  • Payoff mechanism: specifies the payoff perceived by agents

  • Revision process: determines how agents update their strategies

  • Simulator: orchestrates and runs the simulation

This example demonstrates how to simulate a simple population game using popgames.

We model the classic Prisoner’s Dilemma, where agents repeatedly choose between two strategies:

  • Cooperate

  • Defect

Although mutual cooperation is socially optimal, evolutionary dynamics often drive the population toward defection.

Define the fitness function

We begin by defining the fitness function for the Prisoner’s Dilemma. The payoff parameters satisfy

\[ T > R > P > S, \]
T > R > P > S

where:

  • T – temptation to defect

  • R – reward for mutual cooperation

  • P – punishment for mutual defection

  • S – sucker’s payoff

The fitness function is then of the form:

\[\begin{split} \mathbf{f}(\mathbf{x}) = \begin{bmatrix}R & S\\ T & P\end{bmatrix}\mathbf{x}, \end{split}\]
f(x) = [[R, S], [T, P]]x

which can be implemented in Python as follows:

import numpy as np

T, R, P, S = 3, 2, 1, 0

def fitness_function(x):
    return np.dot(
        np.array([[R, S], [T, P]]),
        x
    )

Create the population game and payoff mechanism objects

Next we instantiate the population game and payoff mechanism objects by specifying the number of strategies and the fitness function.

from popgames import (
    SinglePopulationGame,
    PayoffMechanism,
)

population_game = SinglePopulationGame(
    num_strategies=2,
    fitness_function=fitness_function,
)

payoff_mechanism = PayoffMechanism(
    h_map=fitness_function,
    n=2,
)

Define the revision process object

Agents revise their strategies according to a Poisson revision process combined with a softmax revision protocol. We therefore define the corresponding revision process object as follows.

from popgames import PoissonRevisionProcess
from popgames.revision_protocol import Softmax

revision_process = PoissonRevisionProcess(
    Poisson_clock_rate=1,
    revision_protocol=Softmax(0.1),
)

Instantiate the simulator and run the simulation

We now create the simulator and run the population dynamics. The simulation considers a population of 1000 agents starting from an equal split between the two strategies.

from popgames import Simulator

sim = Simulator(
    population_game=population_game,
    payoff_mechanism=payoff_mechanism,
    revision_processes=revision_process,
    num_agents=1000
)

x0 = np.array([0.5, 0.5]).reshape(2, 1)  # Initial state

sim.reset(x0=x0)
out = sim.run(T_sim=30)

Visualize the results

Finally, we visualize the evolution of the population state using matplotlib.

import matplotlib.pyplot as plt

plt.figure(figsize=(3, 3))

plt.plot(out.t, out.x[0, :], label="Cooperators")
plt.plot(out.t, out.x[1, :], label="Defectors")

plt.xlabel("Time")
plt.ylabel("Population fraction")
plt.legend()
plt.grid()

plt.tight_layout()
plt.show()

PopGames also provides built-in visualization utilities supporting ternary plots, univariate projections, and custom key performance indicators. For more details, see the API reference documentation.

For the considered example, if everything works as expected, you should see a plot like:

Prisoner's Dilemma trajectory

What happens?

Starting from a balanced population, the evolutionary dynamics gradually favor defection, illustrating the well-known outcome of the Prisoner’s Dilemma in evolutionary settings.

Documentation

  • Usage Examples – hands-on full usage examples

  • Key Concepts – connections with theoretical background

  • API Reference – full codebase documentation

  • Contributing to PopGames - how to contribute to the PopGames package
